Punch - tonnage: 75 tons
- hole capacity: 1-1/16" in 3/4" mild steel
7/8" in 7/8" mild steel
- throat depth: 12"
Shear - angles (90°): 6" x 6" x 1/2"
- plates: 18" x 5/8"
- length of blades: 19"
Bar cutter - rounds: 1-3/4"
- squares: 1-3/4"
Notcher: 3/8" thick
EQUIPPED WITH: Free standing control with dual palm
buttons
Dual electric foot switch
Selector switch for norm - inch,
holddown on - off &
emergency stop button
Punch & die holder
One shot oil lubrication
Hydraulic pump, driven by
10 HP
Imperial
| Tonnage | 75 T |
| Angle (L1) | 6" |
| Angle (L2) | 6" |
| Angle (T) | 1.5" |
| Power | 10 hp |
| Throat | 12" |
| Stroke | 2" |
| Dimensions | 45" L-R x 71" F-B x 81" H |
| Weight | 4,200 Lbs. |
Punch - tonnage: 75 tons
- hole capacity: 1-1/16" in 3/4" mild steel
7/8" in 7/8" mild steel
- throat depth: 12"
Shear - angles (90°): 6" x 6" x 1/2"
- plates: 18" x 5/8"
- length of blades: 19"
Bar cutter - rounds: 1-3/4"
- squares: 1-3/4"
Notcher: 3/8" thick
EQUIPPED WITH: Free standing control with dual palm
buttons
Dual electric foot switch
Selector switch for norm - inch,
holddown on - off &
emergency stop button
Punch & die holder
One shot oil lubrication
Hydraulic pump, driven by
10 HP
