10' x 14 Gauge Schechtl MAB 310 CNC Folder, New AMS Control

10' x 14 Gauge Schechtl MAB 310 CNC Folder, New AMS Control

Have one to sell?
385-855-1585
Sales@usedfabmachines.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
Folding Machines
Manufacturer:
SCHECHTL
Model:
MAB 310
Year:
1999
Status:
For Sale
Serial #:
2999
Country:
United States
Max Thickness2 mm0.0787"
Max Thickness (gauge)14 gauge14 gauge
Overall Length122"3.1 m
ControlCNC (AMS)CNC (AMS)
Dimensions158"L x 79"W x 59"H158"L x 79"W x 59"H
Weight7,300 Lbs.7,300 Lbs.

Working Length: 122"
Capacity: 14 gauge CRS
Folding Beam Speed: 85°/sec
Folding Beam Arc: 0–160° (with 20° degrees)
Upper Beam Speed: 2.5"/sec
Backgauge Depth: 39.5"
Backgauge Accuracy: ± .004"

Electrical Requirements
3 Phase, 60 Hz
230V @ 20 Amps

All specifications are assumed to be correct but must be confirmed by the purchasing entity

New AMS Control
Machine has been completely serviced and gone through by 3rd party tech
