| Tonnage | 325 T | 294.835 t |
| Type | HYD | HYD |
| Overall Length | 12' | 3.7 m |
| Between Housings | 10' | 3 m |
| Stroke | 8" | 203.2 mm |
| Dimensions | 13′ L x 7′ W x 10.5′ H | 13′ L x 7′ W x 10.5′ H |
| Weight | 50,000 lbs. | 50,000 lbs. |
Forming Tonnage: 325 Tons
Punching Capacity: 230 Tons
Bed/Ram Length: 12 feet (144 inches)
Distance Between Housings: 10 feet 5 inches
Ram Stroke: 8 inches (adjustable)
Open Height: 16 inches
Closed Height: 8 inches
Throat Depth: 10 inches
Main Motor: 30 HP
Operating Speeds
Approach: 90–112 IPM (inches per minute)
Pressing: 18 IPM
Return: 89–116 IPM
Tooling Included
Adjustable blocks on the backgauge
