| Tonnage | 257 T | 233.147 t |
| Type | HYD | HYD |
| Overall Length | 13' | 4 m |
| Between Housings | 12' | 3.7 m |
| Stroke | 17.51" | 444.75 mm |
| # Axis | 6 | 6 |
| Control | CNC (Trumpf CNC Control) | CNC (Trumpf CNC Control) |
| Weight | 42,000 lbs | 42,000 lbs |
Tonnage: 257 Ton
Overall Bending Length: 13’4″
Distance Between Housings: 12’1″
Max. Stroke: 17.51”
Throat Depth: 16.5”
Open Height: 21”
Max. Operating Press: 4350 psi
Weight: 42336 lbs
Voltage: 3 x 460 V
Full Load Current: 63,0 A
Frequency: 60 Hz
Electrical Connection: 50.0 kVa
Amp Rating of Largest Motor: 53.0 A
Trumpf CNC Control w/ 6-Axis Backgauge
CNC Crowning
Hydraulic Tool Clamping
Sheet Bending Aid
I- Axis
