| Tonnage | 90 T | 81.647 t |
| Type | HYD | HYD |
| Overall Length | 8' | 2.4 m |
| Between Housings | 6" | 0.2 m |
| Stroke | 14" | 355.6 mm |
| # Axis | 3 | 3 |
| Dimensions | 102” x 60” x 112” High | 102” x 60” x 112” High |
| Weight | 12,000 lbs. | 12,000 lbs. |
SPECIFICATIONS:
Capacity…………………………………… 90 Tons
Overall Length:…………………………. 8’
Between the Housings:…………….. 6’
Stroke:……………………………………….14”
Open Daylight:………………………….. 21”
Closed Daylight…………………………. 7”
Bending Capacity:……………………….5’ x ¼”
………………………………………6’8” x 3/16”
Ram Speed………………………………….Approach 200 IMP
Bending High: 55 IPM
Bending Medium: 20 IPM
Bending Low: 5 IPM
Return: 185 IPM
Backgauge Range:………………………24”
Number of Backgauge Axis’:……… 2
Dimensions: ………………………………. 102” x 60” x 112” High
Weight Approx. …………………………. 12,000 Lbs.
